1. Drive system with high precision linear guide and slide block, high precision, wear resistance, small resistance, high speed; arc-gear synchronous belt 3m, stable transmission, strong shock absorption ability and small noise.
2. Red Cross accurate positioning, convenient and quick in finding engraving and cutting position.
3. Three-mirrors and one focal lens path system to deliver outstanding engraving and cutting effect.
4. Equipped with manual modulation focused laser head, responsive and accurate, the machine can adjust the focus position according to engraving and cutting alternation and the material characteristics and thickness of the plank, to ensure sculpture quality.
|
Power |
80-300w |
|
Cutting thickness |
0-30mm |
|
Supply Voltage |
AC 110v-220v±10% |
|
engraving speed |
0-64000mm/min |
|
cutting speed |
0-36000mm/min |
|
Positioning accuracy |
≤±0.05mm |
|
Operating humidity |
5%-95% |
|
Working temperature |
0-45° |
|
Working area |
1300*2500mm |
|
Packaging size |
3770*2130*1300 |
|
Data transmission interface |
USB |
|
Cooling mode |
Water-cooling and protection system |
|
Graphic file format |
PLT,DST,DXF,DWG,AI,LAS |
|
Gross Weight |
940KG |
| Packaging inclusion | software ,video user manual,air pump,power cables, usb cables, water tank, water pipe,smoke vent pipe, air blow pipe,exhaust fan,tools bag. |
| Options parts | water chiller/ laser head/ rotary/ up-down table |
| Guarantee | 1 years |
Laser engraving machine can work with most materials, such as Cloth, leather, wool, acrylic, plexiglass, board, plastic, rubber, crystal, ceramic tile, bamboo product, jade, granite, marble, resin and other non-metal materials.
Laser engraving machine is suitable for leather clothing, template cutting, printing and packaging, advertisement decoration, building decoration, computer embroidery tailoring, arts and crafts, paper products, plastic industry, acrylic board, decorative board, and other non metal sheet precision cutting and other industries
