1390 Co2 Laser Cutter Engraver Machine

1390 Co2 Laser Cutter Engraver Machine

1390 machine features

1) working area:1300*900mm, could be changed and designed by our professional design team
2) high precision guarantee
3) perfect after-sale service and high quality make sure customer use machine well.
4) most reasonable price make customer could accept it.
5)Working table: Open blade with special treated material. Never fray and easy operation, suitable for all kinds of hard materials.
6)Steady chassis: Stability and precision during high speed work.
7)High efficiency tube with stable laser path, life time around 10,000 hours.

1390 Co2 Laser Cutter Engraver Machine

Features

1. Mixing cutting capacity of the machine: for stainless steel, carbon steel, acrylic, and wood

2. High-precision machine: X / Y use high accuracy motor and driver, with high-precision belt conveyor, greatly improve the response speed and precision cutting equipment, extend the life of the product.

3. Stability: optimized CNC control system can meet the precision machining parts, and stable dynamic performance, sustainable work long hours.

4. Good cutting section quality: mechanical cutting head system, the level of the cutting head with the follower plate, cutting position remains the same, the slit is smooth, no post-order processing section, to adapt to flat or curved sheet metal cutting.

5. The laser structure is simple, easy to operate, stable laser operation, low maintenance costs.

Technical Parameters

 Model YN-1390

Working area 1300*900 mm

Working Voltage AC 110V or 220V±10% 50 HZ -60 HZ

Laser power EFR 80W 100W 130W or RECI laser optional

Control system Ruida control technology

Cutting head Single Laser Head with red dot pointer and air assist

Driving system Leadshine stepper moters & drive

Working table Blade table

Cooling way water cooling

Front and back door Yes, it for long material pass though

linear guide rail Taiwan PMI linear guide rail

Support Graphic Format BMP, PLT, DST, DXF, AI,RLD

Compatible Software CorelDraw, AutoCAD, Photoshop, Illustrator

Operating temperature 0 -45 degree

Engraving speed 72000 mm/min

Cutting speed 36000 mm/min

Materials

 >>Applicable materials:
wood, bamboo, jade, marble, organic glass, crystal, plastic, garments, paper, leather, rubber, ceramic, glass and other nonmetal materials.

Samples


[!--empirenews.page--]

[!--empirenews.page--]

[!--empirenews.page--]

[!--empirenews.page--]

[!--empirenews.page--]

Application

 >>Applicable industries:
advertisement, arts and crafts, leather, toys, garments, model , building upholster, computerized embroidery and clipping, packaging and paper industry.
