1. Working Area: this can be customized according to your requirements
2. RD control system:there has the USB interface in the control panel, do not need to connect into the computer, supporting offline work, very convenient
3. Knife worktable/Honeycomb worktable for your option -Knife worktable is better for hard materials such as wood,acrylic; Honeycomb worktable use for soft materials such as leather,fabric etc
4. High resolution laser head:good quality and long lifetime
5. Water pump/ Industrial chillier:used for cooling laser tube to protect it has long life.
6. Air pump/Compressor:cooling the laser head to avoid the materials being burned.
7. Exhaust fan: Blow away the smoke
8. Tool box-Included the CD,User manual,and some wrenches for your work.
|
Working area |
900*600mm |
|
Laser power |
60W 80W 100W 130W 150W |
|
Laser type |
sealed CO2 laser tube,10.6μm |
|
Working platform |
honeycomb or blade |
|
Engraving speed |
0-40000mm/min |
|
Resolution rate |
±0.01mm |
|
Power Supply |
AC110V/220V±10%,50HZ/60HZ |
|
Supported Graphic Formats |
BMP,PLT,DST,AI,HPGL |
|
Cooling Mode |
Water cooling and protection system |
|
Control software |
RD Control System |
|
Driving system |
High-precision 3-phase stepper motor |
|
Compatible software |
Core Draw Auto CAD Photoshop |
|
Working temperature |
0~45℃ |
|
Working humidity |
5%~95% (without condensed water) |
|
Color Separation |
Yes |
|
Optional Configuration |
UP&down table,Rotary device, Auto focus device |
Available for engraving and cutting such nonmetal metal hard material as acrylic,color plates,ABS board,rubber,plastic,cloth toys,leather,wool,crystal,glass,ceramic tile,jade,bamboo products,wood products. advertising and building decoration,packaging and printing,paper products industries
\
Applied to cloth,leather,toys,computer embroidery cutting,mould,crafts,bamboo and wood.
